FEATURES:

4,500kg MAX. TOW  CAPACITY.  450kg MAX. T.W.

  • · TESTED & COMPLIANT WITH ADR62/02.
  • · TESTED UP TO 6,750kg (LONGITUDINAL TENSION).
  • · SOLID STEEL SHANK WITH DUAL GUSSETS FOR SUPERIOR STRENGTH.
  • · SUITS 50mm OR 70mm TOW BALLS. (sold separatly)
  • · REVERSIBLE SHANK & BALL PLATFORM GIVE GREATER DROP OR RISE HEIGHT.
  • · 16 STAGE ADJUSTMENTS MAX RISE 188mm MAX DROP 210mm. (32mm increments)
  • · OPTIONAL SHANKS CAN GIVE A DROP OF 370mm & RISE UP TO 350mm
  • · MULTI-PIN HOLES GIVE 3 LENGTH ADJUSTMENTS. 315-340-365mm.
  • · H.T. 3/4” BOLTS, NYLOC LOCKING NUTS AND TOOTHED CONICAL WASHERS GIVES SUPERIOR STRENGTH.
  • · POWDER COATED ENAMEL FINISH GIVES GREATER PROTECTION FROM THE ELEMENTS.
  • · COMPATIBLE WITH HITCHMASTER DO35 & DO45, TREG, McHITCH, ALKO, OZ HITCH 4.5T & ARK COUPLINGS.  ALSO SUITABLE FOR THE FORD RANGER SHORT SHANK TOW BAR.
  • · MANUFACTURED TO MISTER HITCHES STRICT QUALITY AND SPECIFICATIONS.

PART NUMBER:  MHABM45-1

(MHABM45-1)

SKU MHABM45-1
Brand Mister Hitches
Shipping Weight 5.0000kg
Shipping Width 0.400m
Shipping Height 0.100m
Shipping Length 0.400m
Shipping Cubic 0.016000000m3
